TC Helicon VoiceTone Double
-
- nicht lieferbar - ARCHIV
- Bestellnr.: 220622
TC Helicon (T.C.Electronic) VoiceTone Double
Live-Overdubbing im Pedalformat. Ein Vocal-Pedal, mit dem du bis zu vier natürlich klingende Overdubs erzeugen kannst - live! Ob kompakt und nah oder locker und lebendig - die Overdub-Stimmen aus dem VoiceTone können so klingen, wie du es dir wünschst. Ob realistisches oder mit Effekten angereichtes Doubling - mit dem VoiceTone klingst Du auf der Bühne ebenso gut wie auf CD.
technische Details:
- Analog Inputs:
- Connectors Balanced: XLR
- Input Impedance: 1 kOhm
- Mic Input Sensitivity @ 0 dBFS: -44 dBu to +2 dBu
- Mic Input Sensitivity @ 12 dB headroom: -56 dBu to -10 dBu
- EIN: -128 dBu @ max. mic amp gain, Rg = 150 Ohm
- Analog Outputs:
- Connectors: Balanced XLR
- Output Impedance: 40 Ohm
- Output Level @ 0dBFS: +2dBu
- Input to Output Analog Audio Performance:
- Dynamic Range, Mic. @ Min gain: >108 dB, 20 Hz - 20 kHz (A-weighted)
- Dynamic Range, Mic. @ -18dBu sensitivity: > 104dB, 20hz – 20kHz (A-weighted)
- THD+ Noise, Mic. @ Min gain: <-90dB
- Frequency Response, max gain: -1.5 dB @ 40 Hz, +0/-0.3 dB (200 Hz to 20 kHz)
- Conversion Characteristics:
- Sample Rate: 48 kHz
- Converter: AKM AK4620B
- A to D / D to A Conversion: 24 bit, 128x oversampling bitstream
- A to D Delay: 0.65 ms
- D to A Delay: 0.63 ms
- EMC
- Complies with: EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
- Safety:
- Certified to: IEC 65, EN 60065, UL6500 and CSA E60065 CSA FILE #LR108093
- Environment:
- Operating Temperature: 0° C to 50° C
- Storage Temperature: -30° C to 70° C
- Humidity: Max. 90 % non-condensing
- Supplementary:
- Maße: 130mm x 132mm x 41mm
- Gewicht: 0.72 kg
- Warranty Parts and labor: 1 year
